产品描述
| 50×50×10MM-1 | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HBS0505HG-1 | Sleeve | 5 | 4.0 | 0.25 | 1.25 | 5500 | 0.09 | 3.12 | 9.41 | 0.37 | 31.4 | |
| HBS0505MG-1 | 4.0 | 0.18 | 0.90 | 4500 | 0.07 | 2.55 | 5.48 | 0.22 | 27.4 | |||
| HBS0505LG-1 | 4.0 | 0.15 | 0.75 | 3500 | 0.05 | 1.94 | 3.05 | 0.12 | 20.8 | |||
| HBB0505HG-1 | Ball | 4.0 | 0.25 | 1.25 | 5500 | 0.09 | 3.12 | 9.41 | 0.37 | 31.4 | ||
| HBB0505MG-1 | 4.0 | 0.18 | 0.90 | 4500 | 0.07 | 2.55 | 5.48 | 0.22 | 27.4 | |||
| HBB0505LG-1 | 4.0 | 0.15 | 0.75 | 3500 | 0.05 | 1.94 | 3.05 | 0.12 | 20.8 | |||
| HBS0512HG-1 | Sleeve | 12 | 4.0 | 0.15 | 1.80 | 5500 | 0.09 | 3.12 | 9.41 | 0.37 | 31.4 | |
| HBS0512MG-1 | 4.0 | 0.10 | 1.20 | 4500 | 0.07 | 2.55 | 5.48 | 0.22 | 27.4 | |||
| HBS0512LG-1 | 4.0 | 0.08 | 0.96 | 3500 | 0.05 | 1.94 | 3.05 | 0.12 | 20.8 | |||
| HBB0512HG-1 | Ball | 6.0 | 0.15 | 1.80 | 5500 | 0.09 | 3.12 | 9.41 | 0.37 | 31.4 | ||
| HBB0512MG-1 | 6.0 | 0.10 | 1.20 | 4500 | 0.07 | 2.55 | 5.48 | 0.22 | 27.4 | |||
| HBB0512LG-1 | 6.0 | 0.08 | 0.96 | 3500 | 0.05 | 1.94 | 3.05 | 0.12 | 20.8 | |||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
