产品描述
| 45×45×05MM | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HBH4505HV | Hydraulic | 5 | 4.0 | 0.25 | 1.25 | 5200 | 0.04 | 1.55 | 9.72 | 0.38 | 25.4 | |
| HBH4505MV | 4.0 | 0.20 | 1.00 | 4500 | 0.04 | 1.34 | 8.41 | 0.33 | 22.0 | |||
| HBH4505LV | 4.0 | 0.15 | 0.75 | 3500 | 0.03 | 1.04 | 6.54 | 0.26 | 17.1 | |||
| HBH4512HV | 12 | 6.0 | 0.20 | 2.40 | 5200 | 0.04 | 1.55 | 9.72 | 0.38 | 25.4 | ||
| HBH4512MV | 6.0 | 0.15 | 1.80 | 4500 | 0.04 | 1.34 | 8.41 | 0.33 | 22.0 | |||
| HBH4512LV | 6.0 | 0.10 | 1.20 | 3500 | 0.03 | 1.04 | 6.54 | 0.26 | 17.1 | |||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
关于我们
获得最新报价
45x45x05mm
MOQ：
价格：
