303010mm圆框
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Part NO.	Function	System	VDC	VDC	A	W	RPM	M³/min	CFM	mmH₂O	INH₂O	dBA
HDS0305HG		Sleeve	5	4.0	0.30	1.50	9000	0.09	3.03	3.43	0.14	26.6
HDS0305MG				4.0	0.18	0.90	7500	0.08	2.72	2.42	0.10	23.6
HDS0305LG				4.0	0.12	0.60	6000	0.05	1.76	1.34	0.05	19.8
HDB0305HG		Ball		4.0	0.30	1.50	9000	0.09	3.03	3.43	0.14	26.6
HDB0305MG				4.0	0.18	0.90	7500	0.08	2.72	2.42	0.10	23.6
HDB0305LG				4.0	0.12	0.60	6000	0.05	1.76	1.34	0.05	19.8
HDS0312HG		Sleeve	12	9.0	0.10	1.20	9000	0.09	3.03	3.43	0.14	26.6
HDS0312MG				9.0	0.08	0.96	7500	0.08	2.72	2.42	0.10	23.6
HDS0312LG				9.0	0.06	0.72	6000	0.05	1.76	1.34	0.05	19.8
HDB0312EG		Ball		9.0	0.21	2.52	12000	0.12	4.28	5.74	0.23	34.0
HDB0312UG				9.0	0.13	1.56	10500	0.10	3.42	4.28	0.17	31.4
HDB0312HG				9.0	0.10	1.20	9000	0.09	3.03	3.43	0.14	26.6
HDB0312MG				9.0	0.08	0.96	7500	0.08	2.72	2.42	0.10	23.6
HDB0312LG				9.0	0.06	0.72	6000	0.05	1.76	1.34	0.05	19.8
HDS0324HG		Sleeve	24	12.0	0.07	1.68	9000	0.09	3.03	3.43	0.14	26.6
HDS0324MG				12.0	0.06	1.44	7500	0.08	2.72	2.42	0.10	23.6
HDS0324LG				12.0	0.04	0.96	6000	0.05	1.76	1.34	0.05	19.8
HDB0324HG		Ball		12.0	0.07	1.68	9000	0.09	3.03	3.43	0.14	26.6
HDB0324MG				12.0	0.06	1.44	7500	0.08	2.72	2.42	0.10	23.6
HDB0324LG				12.0	0.04	0.96	6000	0.05	1.76	1.34	0.05	19.8
Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing

30*30*10mm

DC-轴流风扇
