| 40×40×28MM-3 | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HDB0412SB-3 | -A | Ball | 12 | 6.0 | 1.05 | 12.60 | 22000 | 0.74 | 26.19 | 77.10 | 3.04 | 62.5 |
| HDB0412VB-3 | -A | 0.66 | 7.92 | 18000 | 0.61 | 21.43 | 51.61 | 2.03 | 58.1 | |||
| HDB0424SB-3 | -A | 24 | 18.0 | 0.53 | 12.72 | 20000 | 0.67 | 23.81 | 63.72 | 2.51 | 60.4 | |
| HDB0424VB-3 | -A | 0.45 | 10.80 | 18000 | 0.61 | 21.43 | 51.61 | 2.03 | 58.1 | |||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
