产品描述
| 80×80×10MM-1 | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HYS0812HG-1 | Sleeve | 12 | 6.0 | 0.20 | 2.40 | 3000 | 0.69 | 24.28 | 1.97 | 0.08 | 27.4 | |
| HYS0812MG-1 | 6.0 | 0.15 | 1.80 | 2500 | 0.58 | 20.49 | 1.45 | 0.06 | 23.9 | |||
| HYS0812LG-1 | 6.0 | 0.10 | 1.20 | 2000 | 0.46 | 16.13 | 0.93 | 0.04 | 20.4 | |||
| HYB0812HG-1 | Ball | 6.0 | 0.20 | 2.40 | 3000 | 0.69 | 24.28 | 1.97 | 0.08 | 27.4 | ||
| HYB0812MG-1 | 6.0 | 0.15 | 1.80 | 2500 | 0.58 | 20.49 | 1.45 | 0.06 | 23.9 | |||
| HYB0812LG-1 | 6.0 | 0.10 | 1.20 | 2000 | 0.46 | 16.13 | 0.93 | 0.04 | 20.4 | |||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
