45×45×10mm
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Part NO.	Function	System	VDC	VDC	A	W	RPM	M3/min	CFM	mmH2O	INH2O	dBA
HBS4505HG		Sleeve	5	4.0	0.11	0.55	5500	0.08	2.84	9.84	0.39	29.4
HBS4505MG				4.0	0.07	0.35	4500	0.07	2.31	5.91	0.23	25.8
HBS4505LG				4.0	0.05	0.25	3500	0.05	1.88	3.24	0.13	20.8
HBB4505HG		Ball		4.0	0.11	0.55	5500	0.08	2.84	9.84	0.39	29.4
HBB4505MG				4.0	0.07	0.35	4500	0.07	2.31	5.91	0.23	25.8
HBB4505LG				4.0	0.05	0.25	3500	0.05	1.88	3.24	0.13	20.8
HBS4512HG		Sleeve	12	4.0	0.11	0.55	5500	0.08	2.84	9.84	0.39	29.4
HBS4512MG				4.0	0.07	0.35	4500	0.07	2.31	5.91	0.23	25.8
HBS4512LG				4.0	0.05	0.25	3500	0.05	1.88	3.24	0.13	20.8
HBB4512HG		Ball		6.0	0.11	0.55	5500	0.08	2.84	9.84	0.39	29.4
HBB4512MG				6.0	0.07	0.35	4500	0.07	2.31	5.91	0.23	25.8
HBB4512LG				6.0	0.05	0.25	3500	0.05	1.88	3.24	0.13	20.8
Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing

45x45x10mm

DC-轴流风扇
