92×92×25mm
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Part NO.	Function	System	VDC	VDC	A	W	RPM	M3/min	CFM	mmH2O	INH2O	dBA
HBS0912HA		Sleeve	12	5.0	0.60	7.20	5000	1.25	44.13	25.13	0.99	54.1
HBS0912MA				5.0	0.40	4.80	4000	0.93	32.81	19.50	0.77	47.8
HBS0912LA				5.0	0.20	2.40	3500	0.81	28.77	17.50	0.69	45.4
HBB0912HA		Ball		5.0	0.60	7.20	5000	1.25	44.13	25.13	0.99	54.1
HBB0912MA				5.0	0.40	4.80	4000	0.93	32.81	19.50	0.77	47.8
HBB0912LA				5.0	0.20	2.40	3500	0.81	28.77	17.50	0.69	45.4
HBS0924HA		Sleeve	24	12.0	0.60	14.40	5000	1.25	44.13	25.13	0.99	54.1
HBS0924MA				12.0	0.50	12.00	4000	0.93	32.81	19.50	0.77	47.8
HBS0924LA				12.0	0.30	7.20	3500	0.81	28.77	17.50	0.69	45.4
HBB0924HA		Ball		12.0	0.60	14.40	5000	1.25	44.13	25.13	0.99	54.1
HBB0924MA				12.0	0.50	12.00	4000	0.93	32.81	19.50	0.77	47.8
HBB0924LA				12.0	0.30	7.20	3500	0.81	28.77	17.50	0.69	45.4
Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing

92x92x25mm

DC-轴流风扇
