60×60×10mm
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Part NO.	Function	System	VDC	VDC	A	W	RPM	M3/min	CFM	mmH2O	INH2O	dBA
HDS0605HG		Sleeve	5	4.0	0.28	1.40	4000	0.43	15.09	2.31	0.09	29.2
HDS0605MG				4.0	0.25	1.25	3500	0.38	13.29	1.81	0.07	26.8
HDS0605LG				4.0	0.20	1.00	3000	0.31	10.84	1.26	0.05	23.0
HDB0605HG		Ball		4.0	0.28	1.40	4000	0.43	15.09	2.31	0.09	29.2
HDB0605MG				4.0	0.25	1.25	3500	0.38	13.29	1.81	0.07	26.8
HDB0605LG				4.0	0.20	1.00	3000	0.31	10.84	1.26	0.05	23.0
HDS0612HG		Sleeve	12	6.0	0.22	2.64	4000	0.43	15.09	2.31	0.09	29.2
HDS0612MG				6.0	0.18	2.16	3500	0.38	13.29	1.81	0.07	26.8
HDS0612LG				6.0	0.16	1.92	3000	0.31	10.84	1.26	0.05	23.0
HDB0612HG		Ball		6.0	0.22	2.64	4000	0.43	15.09	2.31	0.09	29.2
HDB0612MG				6.0	0.18	2.16	3500	0.38	13.29	1.81	0.07	26.8
HDB0612LG				6.0	0.16	1.92	3000	0.31	10.84	1.26	0.05	23.0
Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing

60x60x10mm

DC-轴流风扇
