80×80×38mm-1
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Part No.	Function	System	VDC	VDC	A	W	RPM	m3/min	CFM	mmH2O	INH2O	dBA
HDB0812VF-1	-A	Ball	12	6.0	1.50	18.00	7500	2.99	105.56	24.24	0.95	55.1
HDB0812EF-1	-A			6.0	1.15	13.80	6600	2.59	91.39	18.44	0.73	52.7
HDB0812UF-1	-A			6.0	0.90	10.80	5700	2.21	77.93	14.45	0.57	49.4
HDB0812HF-1	-A			6.0	0.58	6.96	4900	1.89	66.90	10.66	0.42	44.7
HDB0812MF-1	-A			9.0	0.38	4.56	4200	1.63	57.53	7.89	0.31	40.0
HDB0812LF-1	-A			9.0	0.20	2.40	3400	1.27	44.85	5.10	0.20	34.8
HDB0824VF-1	-A	Ball	24	12.0	0.80	19.20	7500	2.99	105.56	24.24	0.95	55.1
HDB0824EF-1	-A			12.0	0.60	14.40	6600	2.59	91.39	18.44	0.73	52.7
HDB0824UF-1	-A			12.0	0.50	12.00	5700	2.21	77.93	14.45	0.57	49.4
HDB0824HF-1	-A			12.0	0.34	8.16	4900	1.89	66.90	10.66	0.42	44.7
HDB0824MF-1	-A			18.0	0.24	5.76	4200	1.63	57.53	7.89	0.31	40.0
HDB0824LF-1	-A			18.0	0.15	3.60	3400	1.27	44.85	5.10	0.20	34.8
Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing

80x80x38mm-1

DC-轴流风扇
