| 75×75×25-2MM | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HBS7512HA-2 | -A | Sleeve | 12 | 5.0 | 0.40 | 4.80 | 4500 | 0.38 | 13.50 | 25.50 | 1.00 | 49.5 |
| HBS7512MA-2 | 5.0 | 0.30 | 3.60 | 3500 | 0.32 | 11.20 | 16.20 | 0.64 | 43.5 | |||
| HBS7512LA-2 | 5.0 | 0.20 | 2.40 | 2500 | 0.21 | 7.30 | 6.45 | 0.25 | 34.5 | |||
| HBB7512HA-2 | ball | 5.0 | 0.40 | 4.80 | 4500 | 0.38 | 13.50 | 25.50 | 1.00 | 49.5 | ||
| HBB7512MA-2 | 5.0 | 0.30 | 3.60 | 3500 | 0.32 | 11.20 | 16.20 | 0.64 | 43.5 | |||
| HBB7512LA-2 | 5.0 | 0.20 | 2.40 | 2500 | 0.21 | 7.30 | 6.45 | 0.25 | 34.5 | |||
| HBS7524HA-2 | -A | Sleeve | 24 | 12.0 | 0.35 | 8.40 | 4500 | 0.38 | 13.50 | 25.50 | 1.00 | 49.5 |
| HBS7524MA-2 | 12.0 | 0.25 | 6.00 | 3500 | 0.32 | 11.20 | 16.20 | 0.64 | 43.5 | |||
| HBS7524LA-2 | 12.0 | 0.15 | 3.60 | 2500 | 0.21 | 7.30 | 6.45 | 0.25 | 34.5 | |||
| HBB7524HA-2 | -A | ball | 12.0 | 0.35 | 8.40 | 4500 | 0.38 | 13.50 | 25.50 | 1.00 | 49.5 | |
| HBB7524MA-2 | 12.0 | 0.25 | 6.00 | 3500 | 0.32 | 11.20 | 16.20 | 0.64 | 43.5 | |||
| HBB7524LA-2 | 12.0 | 0.15 | 3.60 | 2500 | 0.21 | 7.30 | 6.45 | 0.25 | 34.5 | |||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
