| 92*92*38MM | ||||||||||||
| Model | Bearing | Rated Voltage | Voltage Range | Freq. | Current | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Type | System | VAC | VAC | Hz | A | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HAB92110H38 | W/T | Ball | 110 | 100-125 | 50/60 | 0.16/0.14 | 2500/2700 | 1.42/1.56 | 50/55 | 5.1/5.6 | 0.20/0.22 | 39/41 |
| HAB92220H38 | W/T | Ball | 220 | 200-240 | 50/60 | 0.08/0.07 | 2500/2700 | 1.42/1.56 | 50/55 | 5.1/5.6 | 0.20/0.22 | 39/41 |
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
