Product introduction:
| Size: | 80x80x25mm |
|---|---|
| Material: | Environmental protection and fire protection PBT UL 94V-0 |
| Operating voltage: | 5V 12V |
| Bearing structure: | Hydraulic Bearingor Two Ball Bearing |
| Product life: | 40,000 hours |
| Output function: | FG function RD function PWM function |
| Operating temperature: | -10℃ ~70℃ |
| Storage temperature: | -40℃ ~75℃ |
| 80×80×25MM | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HBH0812HA | Hydraulic/TWO BALL | 12 | 4.0 | 2.80 | 33.60 | 8500 | 3.35 | 118.3 | 41.2 | 1.62 | 63.0 | |
| HBH0812MA | 4.0 | 2.00 | 24.00 | 7500 | 2.86 | 101.2 | 33.1 | 1.30 | 61.5 | |||
| HBH0812LA | 4.0 | 1.00 | 12.00 | 6000 | 2.36 | 83.4 | 20.8 | 0.82 | 57.0 | |||
| HBH0824HA | 24 | 6.0 | 0.80 | 19.20 | 8500 | 3.35 | 118.3 | 41.2 | 1.62 | 63.0 | ||
| HBH0824MA | 6.0 | 0.50 | 12.00 | 7500 | 2.86 | 101.2 | 33.1 | 1.30 | 61.5 | |||
| HBH0824LA | 6.0 | 0.30 | 7.20 | 6000 | 2.36 | 83.4 | 20.8 | 0.82 | 57.0 | |||
