Product introduction:
| Size: | 80x80x17mm |
|---|---|
| Material: | Environmental protection and fire protection PBT UL 94V-0 |
| Operating voltage: | 5V 12V |
| Bearing structure: | Hydraulic Bearingor Two Ball Bearing |
| Product life: | 40,000 hours |
| Output function: | FG function RD function PWM function |
| Operating temperature: | -10℃ ~70℃ |
| Storage temperature: | -40℃ ~75℃ |
| 80×80×17MM | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HBH0805HD | Hydraulic/ Two Ball | 5 | 4.0 | 0.32 | 1.60 | 3000 | 0.32 | 11.24 | 9.22 | 0.36 | 32.8 | |
| HBH0805MD | 4.0 | 0.25 | 1.25 | 2500 | 0.23 | 8.25 | 3.56 | 0.14 | 22.4 | |||
| HBH0805LD | 4.0 | 0.22 | 1.10 | 2000 | 0.20 | 6.94 | 3.12 | 0.12 | 20.8 | |||
| HBH0812HD | 12 | 6.0 | 0.15 | 1.80 | 3000 | 0.32 | 11.24 | 9.22 | 0.36 | 32.8 | ||
| HBH0812MD | 6.0 | 0.11 | 1.32 | 2500 | 0.23 | 8.25 | 3.56 | 0.14 | 22.4 | |||
| HBH0812LD | 6.0 | 0.09 | 1.08 | 2000 | 0.20 | 6.94 | 3.12 | 0.12 | 20.8 | |||
