Product introduction:

Size: 60x60x07mm
Material: Environmental protection and fire protection PBT UL 94V-0
Operating voltage: 5V 12V 24V
Bearing structure: Hydraulic Bearing
Product life: 40,000 hours
Output function: FG function  RD function PWM function
Operating temperature: -10℃ ~70℃
Storage temperature: -40℃ ~75℃

规格

Size(mm) 60X60X07mm
Rated voltage: 5V,12V
Click for Inqueries
Click to Download pdf

60×60×07MM
Model Bearing Rated Voltage Startup Voltage Current Power Speed Air Flow Static Pressure Noise
Part NO. Function System VDC VDC A W RPM M3/min CFM mmH2O INH2O dBA
HBH0605HQ   Hydraulic 5 4.0 0.50 2.50 3000 0.10 3.59 2.18 0.09 22.9
Bearing Type:S=Sleeve  Bearing   H=Hydraulic Bearing   B=Two Ball Bearing   C=One Ball  One Sleeve  Bearing
