Product introduction:

Size: 95x85x27mm
Material: Environmental protection and fire protection PBT UL 94V-0
Operating voltage: 12V 24V
Bearing structure:  TWO Ball bearings
Product life: 30,000 hours  70,000 hours
Output function: FG function  RD function PWM function
Operating temperature: -10℃ ~70℃
Storage temperature: -40℃ ~75℃
Click for Inqueries
Click to Download pdf

95*85*27MM
Model Bearing Rated Voltage Startup Voltage Current Power Speed Air Flow Static Pressure Noise
Part NO. Function System VDC VDC A W RPM M3/min CFM mmH2O INH2O dBA
HBB9513HB -A Ball 13.5 5.0 0.13 1.69 5000 0.38 13.60 42.60 1.68 52.7
Bearing Type:S=Sleeve  Bearing   H=Hydraulic Bearing   B=Two Ball Bearing   C=One Ball  One Sleeve  Bearing
