Product introduction:
| Size: | 40x40x07mm-1 |
|---|---|
| Material: | Environmental protection and fire protection PBT UL 94V-0 |
| Operating voltage: | 5V 12V 24V |
| Bearing structure: | SLEEVE BEARING |
| Product life: | 30,000 hours |
| Output function: | FG function RD function PWM function |
| Operating temperature: | -10℃ ~70℃ |
| Storage temperature: | -40℃ ~75℃ |
| 40*40*07MM-1 | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HYS0405HQ-1 | Hydraulic Sleeve | 5 | 4.0 | 0.15 | 0.75 | 7000 | 0.14 | 5.06 | 2.09 | 0.08 | 30.7 | |
| HYS0405MQ-1 | 4.0 | 0.13 | 0.65 | 6000 | 0.12 | 4.31 | 1.56 | 0.06 | 27.1 | |||
| HYS0405LQ-1 | 4.0 | 0.11 | 0.55 | 5000 | 0.10 | 3.63 | 1.14 | 0.04 | 23.1 | |||
| HYS0412HQ-1 | Hydraulic Sleeve | 12 | 9.0 | 0.13 | 1.56 | 7000 | 0.14 | 5.06 | 2.09 | 0.08 | 30.7 | |
| HYS0412MQ-1 | 9.0 | 0.09 | 1.08 | 6000 | 0.12 | 4.31 | 1.56 | 0.06 | 27.1 | |||
| HYS0412LQ-1 | 9.0 | 0.07 | 0.84 | 5000 | 0.10 | 3.63 | 1.14 | 0.04 | 23.1 | |||
