Product introduction:
| Size: | 93x93x30mm-2 |
|---|---|
| Material: | Environmental protection and fire protection PBT UL 94V-0 |
| Operating voltage: | 5V 12V 24V |
| Bearing structure: | Oil Bearing Ball Bearing |
| Product life: | 30,000 hours 70,000 hours |
| Output function: | FG function RD function PWM function |
| Operating temperature: | -10℃ ~70℃ |
| Storage temperature: | -40℃ ~75℃ |
| 93*93*30mm-2 | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HBS9312HZ-2 | -A | Sleeve | 12 | 5.0 | 0.90 | 10.80 | 4000 | 0.83 | 29.20 | 25.60 | 1.01 | 52.4 |
| HBS9312MZ-2 | -A | 5.0 | 0.60 | 7.20 | 3000 | 0.53 | 18.90 | 15.30 | 0.60 | 46.8 | ||
| HBS9312LZ-2 | -A | 5.0 | 0.20 | 2.40 | 2000 | 0.38 | 13.50 | 6.50 | 0.26 | 35.8 | ||
| HBB9312HZ-2 | -A | Ball | 5.0 | 0.90 | 10.80 | 4000 | 0.83 | 29.20 | 25.60 | 1.01 | 52.4 | |
| HBB9312MZ-2 | -A | 5.0 | 0.60 | 7.20 | 3000 | 0.53 | 18.90 | 15.30 | 0.60 | 46.8 | ||
| HBB9312LZ-2 | -A | 5.0 | 0.20 | 2.40 | 2000 | 0.38 | 13.50 | 6.50 | 0.26 | 35.8 | ||
| HBS9324HZ-2 | -A | Sleeve | 24 | 12.0 | 0.43 | 10.32 | 4000 | 0.83 | 29.20 | 25.60 | 1.01 | 52.4 |
| HBS9324MZ-2 | -A | 12.0 | 0.31 | 7.44 | 3000 | 0.53 | 18.90 | 15.30 | 0.60 | 46.8 | ||
| HBS9324LZ-2 | -A | 12.0 | 0.12 | 2.88 | 2000 | 0.38 | 13.50 | 6.50 | 0.26 | 35.8 | ||
| HBB9324HZ-2 | -A | Ball | 12.0 | 0.43 | 0.00 | 4000 | 0.83 | 29.20 | 25.60 | 1.01 | 52.4 | |
| HBB9324MZ-2 | -A | 12.0 | 0.31 | 0.00 | 3000 | 0.53 | 18.90 | 15.30 | 0.60 | 46.8 | ||
| HBB9324LZ-2 | -A | 12.0 | 0.12 | 0.00 | 2000 | 0.38 | 13.50 | 6.50 | 0.26 | 35.8 | ||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
