| 150*150*50MM | ||||||||||||
| Model | Bearing | Rated Voltage | Voltage Range | Freq. | Current | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Type | System | VAC | VAC | Hz | A | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HAB150110H50 | W/T | Ball | 110 | 100-125 | 50/60 | 0.37 | 2600/3000 | 4.84/5.52 | 171/195 | 12/14 | 0.47/0.55 | 48/52 |
| HAB150220H50 | W/T | Ball | 220 | 200-240 | 50/60 | 0.25 | 2600/3000 | 4.84/5.52 | 171/195 | 12/14 | 0.47/0.55 | 48/52 |
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
