Product introduction:

Size: 80x80x25mm-3
Material: Environmental protection and fire protection PBT UL 94V-0
Operating voltage: 5V 12V 24V
Bearing structure: Oil Bearing  Ball Bearing
Product life: 30,000 hours  70,000 hours
Output function: FG function  RD function PWM function
Operating temperature: -10℃ ~70℃
Storage temperature: -40℃ ~75℃
Click for Inqueries
Click to Download pdf

80x80x25mm-3
Frame Size(mm) Part NO. Function System VDC VDC A W RPM M3/min CFM mmH2O INH2O dBA
80x80x25mm-3 HYB0812EA-3   Sleeve /Ball 12 6.0  0.38  4.56  4000 1.32  46.57  6.82  0.27  40.7
HYB0812UA-3   6.0  0.28  3.36  3500 1.16  41.09  5.44  0.21  39.4
HYB0812HA-3   6.0  0.23  2.76  3000 0.97  34.21  4.04  0.16  35.5
