Product introduction:

Size: 92x92x25mm-1
Material: Environmental protection and fire protection PBT UL 94V-0
Operating voltage: 5V 12V 24V
Bearing structure: Oil Bearing  Ball Bearing
Product life: 30,000 hours  70,000 hours
Output function: FG function  RD function PWM function
Operating temperature: -10℃ ~70℃
Storage temperature: -40℃ ~75℃
Click for Inqueries
Click to Download pdf

92x92x25mm-1
Frame Size(mm) Part NO. Function System VDC VDC A W RPM M3/min CFM mmH2O INH2O dBA
92x92x25mm-1 HYB0912HA-1   Sleeve /Ball 12 6.0  0.23  2.76  2800 1.21  42.74 3.27 0.13  34.6
HYB0912MA-1   6.0  0.19  2.28  2400 1.02  35.97 2.36 0.09  31.4
HYB0912LA-1   6.0  0.16  1.92  2000 0.70  24.88 1.48 0.06  29.6
