Product introduction:
| Size: | 40x40x10mm-1 |
|---|---|
| Material: | Environmental protection and fire protection PBT UL 94V-0 |
| Operating voltage: | 5V 12V 24V |
| Bearing structure: | Oil-impregnated bearings Ball bearings |
| Product life: | 30,000 hours 70,000 hours |
| Output function: | FG function RD function PWM function |
| Operating temperature: | -10℃ ~70℃ |
| Storage temperature: | -40℃ ~75℃ |
| 40×40×10MM-1(直立叶） | ||||||||||||
| Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
| Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
| HYS0412LG-1 | Sleeve | 12 | 9.0 | 0.07 | 0.84 | 4000 | 0.14 | 4.81 | 1.62 | 0.06 | 16.8 | |
| HYB0412LG-1 | Ball | 9.0 | 0.07 | 0.84 | 4000 | 0.14 | 4.81 | 1.62 | 0.06 | 16.8 | ||
| Bearing Type:S=Sleeve Bearing H=Hydraulic Bearing B=Two Ball Bearing C=One Ball One Sleeve Bearing | ||||||||||||
