Product introduction:

Size: 30x30x10mm
Material: Environmental protection and fire protection PBT UL 94V-0
Operating voltage: 5V 12V 24V
Bearing structure: Oil-impregnated bearings Ball bearings
Product life: 30,000 hours  70,000 hours
Output function: FG function  RD function PWM function
Operating temperature: -10℃ ~70℃
Storage temperature: -40℃ ~75℃
Click for Inqueries
Click to Download pdf

30x30x10mm
Frame Size(mm) Part NO. Function System VDC VDC A W RPM M3/min CFM mmH2O INH2O dBA
30x30x10 HYB0312HG   Hydraulic /Ball 12 9.0  0.10  1.20  9000 0.09  3.03 3.43 0.14  26.6
HYB0312MG   9.0  0.08  0.96  7500 0.08  2.72 2.42 0.10  23.6
HYB0312LG   9.0  0.06  0.72  6000 0.05  1.76 1.34 0.05  19.8
