Product introduction:

Size: 80x80x15mm-1
Material: Environmental protection and fire protection PBT UL 94V-0
Operating voltage: 5V 12V 24V
Bearing structure: Oil Bearing  Ball Bearing
Product life: 30,000 hours  70,000 hours
Output function: FG function  RD function PWM function
Operating temperature: -10℃ ~70℃
Storage temperature: -40℃ ~75℃
Click for Inqueries
Click to Download pdf

80x80x15mm-1
Frame Size(mm) Part NO. Function System VDC VDC A W RPM M3/min CFM mmH2O INH2O dBA
80x80x15mm-1 HYB0812HD-1   Sleeve /Ball 12 6.0  0.23  2.76  3000 1.08  38.10  3.38  0.13  30.9
HYB0812MD-1   6.0  0.16  1.92  2500 0.93  33.02  2.65  0.10  26.7
HYB0812LD-1   6.0  0.09  1.08  2000 0.74  26.13  1.75  0.07  22.1
